Marine cold storage floor Wholesale

Marine cold storage floor Marine cold storage floor Marine cold storage floor Marine cold storage floor
Marine Cold Storage Panels

Marine cold storage floor

The product's panels are constructed from stainless steel sheet metal, available in either SUS304 or SUS316. The core is filled with high-density polyurethane foam, with a closed-cell ratio of ≥95% confirmed by third-party testing, ensuring long-term moisture resistance. The core foaming process is catalyzed by adding a liquid mixture to a high-precision steel mold. After foaming, the foaming is allowed to mature for 24 hours, ensuring a stable core density of 40-50 kg/m³ and preventing shrinkage. Products are cut to length using a CNC panel saw with a blade speed of ≥3000 rpm, ensuring a perpendicularity error of ≤0.3 mm/m. The bond strength between the panel and the core is ≥0.15 MPa, meeting the GB/T 10801.2 test standard. The product is certified by classification societies. Customized designs are available, with prompt delivery and timely coordination. It adopts a "load-bearing frame + panel" composite structure. The frame is galvanized square steel (spacing 300-500mm) to enhance bending resistance. The surface is pressed with diamond or strip anti-slip patterns (depth 1-2mm) to increase the friction coefficient (anti-slip when the ship shakes).

E-mail: [email protected]
Contact Us
  • Marine cold storage floor
  • Marine cold storage floor
  • Marine cold storage floor
  • Marine cold storage floor
PREV：Marine cold storage partitions
NEXT：No previous article

  • The thickness is usually 150mm, 120mm, 100mm. It is used for the ground position of the hull. The length and width can be adjusted according to the drawings and requirements for design and customization.

Related Products

About
Jiangsu Shenkai Marine Equipment Co.,Ltd.

As China Marine cold storage floor Manufacturers and Marine cold storage floor Factory, designs and manufactures marine equipment. Its current product offerings include marine prefabricated cold storage, marine ventilation duct systems, marine covers, marine composite panels, marine interior solutions, fire doors, sanitary unit systems, and other products and services.
Founded in 2023, the company prioritizes technological innovation and continuous improvement as its fundamental strategy and core competitiveness. Through unremitting pursuit and exploration, it provides high-quality products and comprehensive services. Currently, the company boasts ample technical and production capacity, producing and servicing approximately 300 sets of marine cold storage panels annually. It also undertakes the production and service of ventilation duct systems and marine interior projects. The technical performance, structural features, and quality of our products fully meet the requirements and standards of marine and offshore engineering. They are widely used by major domestic shipyards and are on par with similar international products. We are currently exporting products in bulk to countries such as Japan, the Philippines, Singapore, South Korea, Vietnam, and India.
The company prioritizes customer focus and strives to exceed customer expectations, providing comprehensive marine product support services. We are committed to collaborating closely with domestic and international enterprises, sharing resources, and creating shared success.
